Outback Power Systems FLEXmax 60 User Manual

42
Press either the < –EQV> or <+EQV > soft key to change
the EQ voltage, following your battery manufacturer’s
recommendations. Note that the factory default EQ
voltage is set low, the same as the factory default Absorb
voltage. Press the <NEXT> soft key to view the BATTERY
EQUALIZE Time screen.
Press either the <-HRS> or <+HRS> soft key to set
the desired equalization time, up to a seven hour
maximum, always following your battery manufacturer’s
recommendations. Press the <NEXT> soft key to view
the battery equalization start screen.
Manual Mode (default mode)
• Press the <START> soft key to manually begin an
equalization cycle. To stop the cycle, press the <STOP>
soft key.
• EQ-MPPT display indicates the Charge Controller is
trying to reach the target equalize set point.
• Equalize time EQ 0:00 in Hours:Minutes displays after
the equalize set point is reached.
• The incomplete equalization cycle continues into the
next day unless the Charge Controller is powered o
or manually stopped. The remaining EQ time can be
viewed in the Stats menu.
• EQ cycle terminates when EQ time period is reached.
• After equalizing, an EQ DONE message displayed and
a Float cycle begins. This message remains displayed
until a soft key is pressed.
Press the <AUTO> soft key to view the auto equalization
screen.
BATTERY EQUALIZE
Time
01 Hours
EXIT NEXT -HRS +HRS
BATTERY EQUALIZE
Volts
15.0
EXIT NEXT -EQV +EQV
BATTERY EQUALIZE
1 Hours 15.0 Volts
Check water level
BACK AUTO START STOP
