Outback Power Systems FLEXmax 60 User Manual

79
48V PV ARRAY (64v Vmp)
#8 #6 #4 #3 #2 #1 #1/0 #2/0 #3/0 #4/0
10 62 98 156 196 247 312 393 496 627 789
20 31 49 78 98 124 156 197 248 313 395
30 21 33 52 65 82 104 131 165 209 263
40 15 24 39 49 62 78 98 124 157 197
50 12 20 31 39 49 62 79 99 125 158
60 10 16 26 33 41 52 66 83 104 132
70 9 14 22 28 35 45 56 71 90 113
80 8 12 19 24 31 39 49 62 78 99
60V PV ARRAY (80v Vmp)
#8 #6 #4 #3 #2 #1 #1/0 #2/0 #3/0 #4/0
10 77 122 195 245 309 390 492 620 783 987
20 39 61 97 122 155 195 246 310 392 493
30 26 41 65 82 103 130 164 207 261 329
40 19 31 49 61 77 97 123 155 196 247
50 15 24 39 49 62 78 98 124 157 197
60 13 20 32 41 52 65 82 103 131 164
70 11 17 28 35 44 56 70 89 112 141
80 10 15 24 31 39 49 61 78 98 123
72V PV ARRAY (96v Vmp)
#8 #6 #4 #3 #2 #1 #1/0 #2/0 #3/0 #4/0
10 93 147 234 294 371 468 590 745 940 1184
20 46 73 117 147 186 234 295 372 470 592
30 31 49 78 98 124 156 197 248 313 395
40 23 37 58 73 93 117 148 186 235 296
50 19 29 47 59 74 94 118 149 188 237
60 15 24 39 49 62 78 98 124 157 197
70 13 21 33 42 53 67 84 106 134 169
80 12 18 29 37 46 58 74 93 117 148
METRIC
#8…8.37mm
2
#6…13.30mm
2
#4…21.15mm
2
#3…26.7mm
2
#2…33.6mm
2
#1/0…53.5mm
2
#2/0…67.4mm
2
#4/0…107mm
2
WIRE GAUGE
AMPS
WIRE GAUGE
AMPS
WIRE GAUGE
AMPS
NOTE: Numbers in bold might not meet NEC requirements
