Outback Comet Kettle K102 - Page 5

5
3
Attach the Left Rear Leg (C2) and the Grill Bracket (B5) onto the Barbecue Body(B1) using the
M6x12 bolts (D1x2pcs), M6 washers (D4X2pcs) and M6 Nuts(D2x2pcs) as shown. Repeat the
above process for the Right Rear Leg(C3).
Attach the Leg Support Rack (C4) onto the legs as shown.
4
C3
C1
C2
B5
