Outback Excel 310 User Manual

2
CODE PART QTY EX310A EX311A
HOOD
A1
Hood (Pre-Assembled to Body)
1 √ √
A2 Hood Handle 1 √ √
A3 Hood Handle Heat Shield 1 √ √
A4 Heat Indicator 1 √ √
A5 Warming Rack 1 √ √
BODY
B1 Barbecue Body 1 √ √
B2 Burner 1 √ √
B3 Control Panel 1 √ √
B4
Knob (Pre-Assembled)
2 √ √
B5 Flame Tamer Bracket 2 √ √
B6 Flame Tamer 1 √ √
B7 Cooking Grill 1 √ √
B8
Ignition Button (Pre-Assembled)
1 √ √
B9 Control Panel Heat Shield 1 √ √
B10 Main Electrode 1 √ √
B11
Hinge Bracket (Pre-Assembled)
2 √
√
B12 Body Heat Shield 1 √ √
B13 Body Support 2 √ √
B14 Grease Cup Holder 1 √ √
B15 Grease Cup 1 √ √
B16 Hose and Regulator Assembly 1 √+ √+
TROLLEY
C1 Side Shelf 1 √ √
C2 Side Shelf Bracket A 1 √ √
C3 Side Shelf Bracket B 1 √ √
C4 Side Burner Knob 1 √ √
C5 Side Burner Grid 1 √ √
C6 Side Burner Shelf 1 √ √
C7 Side Burner 1 √ √
C8 Side Burner Electrode 1 √ √
C9 Side Burner Valve / Hose Assembly 1 √ √
C10 Left Front Leg 1 √ √
C11 Left Rear Leg 1 √ √
C12 Right Front Leg 1 √ √
C13 Right Rear Leg 1 √ √
C14 Gas Bottle Holder 1 √ √
C15 Leg End Loop 1 √ √
C16 Wheel Spacer 2
√ √
C17 Wheel 2
√ √
C18 Wheel Hubcap 2
√ √
C19 Axle 1
√ √
C20 Bottom Shelf 1
√ √
C21 Gas Bottle Strap 1 √ √
HARDWARE
D1 M6x15 Bolt 28 √ √
D2 M5x15 Bolt 2 √ √
D3 M5x10 Bolt 2 √ √
D4 M4x10 Bolt 4 √ √
D5 ST4.0x10 Screw 4 √ √
D6 ST4.0x15 Screw 4 √ √
D7 ST4.8x15 Screw 6 √ √
D8 Locknut 2 √ √
D9 M4 Nut 4 √ √
D10 M5 Nut 2 √ √
D11 Spacer 6 √ √
D12 Hose Clip 1 √ √
Parts List
Quantity varies according to model purchased. Specifications subject to change without prior notice. For
more details on hardware, please see the corresponding ‘Hardware Reference Diagram’.
 Pre-Assembled Component
 Quantity varies according to model purchased
Appearance, size, and construction may differ according to model purchased
