A. Parts List
Quantities vary according to model purchased. Specifications subject to change without prior notice. For more details on
hardware, please see ‘Hardware Reference Diagram’.
CODE PART QTY
Outback®
Trooper
Outback®
Hunter
Outback®
Ranger
HOOD
A1
Hood (Pre-Assembled t o Body)
1
A2 Heat Shield 1
A3 Handle 1
A4 Hinge Plate 4
A5 Gasket 4
A6 Hinge Assembl y 2
A7 Hinge Bolt 12
A8 Hinge Nut 12
A9 Heat Gauge 1
A10 Heat Gauge N ut 2
A11 Warming Rack 1
BODY
B1 Cooking Grill
2 2 1
B2 Reversible Cooking Griddle
N/A 1 1
B3 Lava Rock Basket
2 2 1
B4
Lava Roc k (Packed in Basket)
2 2 1
B5
Body (see Part A1: H ood)
1
B6 Sliding Guide 2
B7 Knob
2 3 4
B8 Control Panel 1
B9 Drip Tray 1
B10 Drip Tray Handle 1 1 1 1
B11 Hose and Hose Clip 1
B12 Burner
2 3 4
TROLLEY
C1 Side Shelf 2
C2 Short Leg 2
C3 Long Leg 2
C4 Screen 1
C5 Trolley Base 1
C6 Leg Endcap 2
C7 Axl e 1
C8 Wheel 2
C9 Hubcap 2
HARDWARE
D1 Handle Nut 2
D2 Handle Washer 2
D3 Handle Spacer 2
D4 Handle Bolt 2
D5
D6
D7 Trolley Bolt 24
D8 Body Support Bolt 8
D9 Spac er 8
D10 Wingnut 8
D11 Washer 2
D12 Loc knut 2
Pre-Assembl ed Component
Quantity varies accordi ng to model purchased
Appear ance, size, and c onstruction may differ acc ording to model purchas ed
Outbac k ® Trooper is approved by TUV
