Attach the left / right cabinet panel assembly to the Bottom Panel (C19) using M6x40 Bolts

(D5x8pcs) and M6 Nuts (D6x8pcs) as shown.

Unscrew the Locknuts (D7) from both ends of the Axle (C22).

Slide the axle through the corresponding holes in the left legs. Slide the Wheels (C20) over each

end of the axle. Secure the wheels into place with the locknuts. Place the wheel Hubcaps (C21)

onto the outsides of the wheels.

C19

C20

C21
