Pre-Assembled Component
Quantity varies according to model purchased
Appearance, size, and construction may differ according to model purchased
CODE PART QTY
Outback®
Spectrum 2
Outback®
Spectrum 3
LID
A1 Lid Handle 1
A2 Flat Lid (Pre-Assembled to Body) 1
A3 L/H Lid Handle Bracket 1
A4 R/H Lid Handle Bracket 1
BODY
B1 Body (see Part A2: Flat Lid) 1
B2 Burner
2 3
B3 Control Panel 1
B4 Knob
2 3
B5 Drip Tray 1
B6 Drip Tray Handle 1
B8 Drip Tray Right Bracket 1
B9 Large Cooking Grill (With Cut-out) 1
B10 Small Cooking Grill (2 Burner Cut-out) 1
B11 Small Cooking Griddle (With Cut-out)
1
B12 Flame Tamer 2
B13 Hose and Regulator 1
B14 Warming Rack 1
TROLLEY
C1 Side Shelf 2
C2 Front Left Leg 1
C3 Rear Left Leg 1
C4 Front Right Leg 1
C5 Rear Right Leg 1
C6 Screen 1
C7 Leg Endcap 2
C8 Wheel 2
C9 Hubcap 2
C10 Axle 1
C11 Trolley Base 1
HARDWARE
D1 M5x10 Bolt 2
D2 M5x15 Bolt 4
D3 Ø5 Washer 4
D4 M5 Nut 4
D5 M6x25 Bolt 24
D7 Ø6 Spacer 8
B7 Drip Tray Left Bracket 1
D6 M6x145 Bolt 8
D8 Axle Washer 2
D9 Locknut 2
A. Parts List
Quantities vary according to model purchased. Specifications subject to change without prior notice. For more
details on hardware, please see Hardware Reference Diagram.
