Oval LS5076 - General Specifications; Flow Range; Basic Meter

S-177-1
(
E）

10. GENERAL SPECIFICATIONS
10.1 Flow Range
Size
Nominal Dia.
mm
Oil Service L/h
Kerosene Light Oil (A Heavy Oil) Heavy Oil
50 20 150 ～ 1600 80 ～ 2000 50 ～ 2000
52 25 300 ～ 3000 150 ～ 3800 80 ～ 3800
53 40 600 ～ 5000 300 ～ 6400 150 ～ 6400
55 40 1200 ～ 11000 600 ～ 14000 400 ～ 14000
56 50 2000 ～ 20000 1400 ～ 24000 900 ～ 24000
★NOTE Kerosene : 0.8 ～ 2mPa・s, Light Oil : 2 ～ 5mPa・s, Heavy Oil : 5 ～ 200mPa・s
10.2 Basic Meter
Item Specifications
Application Oil service
Accuracy Within ±0.5％
Operating Temp. Range 0 to ＋120℃
Max. Operating Press. 1.18MPa (12kgf/cm
2
)
Flange Rating JIS 10K RF
Materials
Meter Body FC250
Rotors Special resin
Color Finish Meter Body Munsell 2.5YR6/13
