S-177-1
(
E）
●
Factored Pulse Generator (Option) in Mechanical Register
Item
Specifications
MR Sensor Reed Switch
Output Pulse Type Voltage pulse Open collector Contact-closure pulse
Number of Pulse
(per pointer rev.)
10P 1P
Pulse Width 1ms min.
Duty Factor 40/60 to 60/40
Output Signal Levels
ON : 6.5V min.
OFF : 1V max.
ON : 1V max.
Max. Operating Current 30mA
60mA
(200Ω protective resister provided)
Max. Operating Voltage 40VDC 125VAC, 50VDC
Contact Bounce 0.5ms max.
Life
5×10
7
cycles of operation
(with resistive load at 12VDC, 10mA)
Signal Cable Vinyl-insulated, 4-conductor, shielded (individual element 0.5mm
2
, 7mm in O. D.)
Transmission Length 1kilometer max. (using CVVS cable 1.25 to 2.0mm
2
)
Power 12 to 24VDC±10％
Current Drain 20mA max.
