NOTE: While installing the terminal block into the cover, pull the cable little by little to avoid sag of
individual conductors inside the connector cover.
(6) Slide the cable rubber packing and washer into the innermost part of cover and tighten cable tting screw.
NOTE: To avoid sag of individual conductors inside the connector cover, tighten the screw while pulling the
cable little by little.
(7) Install the cable connector into the register bracket and secure connector fitting screw to complete
assembly (Fig. 6.6).
➡➡
➡➡
