Select to display the time measurement cursor
and menu.
Turn off the cursor measurement.
When the type is selected as CH1 or CH2, press
the arrow keys
to move the cursor line A;
when the type is selected as Time, press the
arrow keys
to move the cursor line a.
When the type is selected as CH1 or CH2, press
the arrow keys
to move the cursor line B;
when the type is selected as Time, press the
arrow keys
to move the cursor line b.
Link A and B. When the type is selected as CH1
or CH2, by pressing the arrow keys
two
cursors can be moved at the same time; when the
type is selected as Time, by pressing the arrow
keys
, two cursors can be moved at the
same time.
Trigger System
The trigger determines when the oscilloscope starts to acquire data and
display waveforms. Once the trigger is set correctly, it can convert an unstable
display into a meaningful waveform.
When the oscilloscope starts to acquire data, it first acquires enough data to
draw the waveform on the left side of the trigger point. The oscilloscope
continuously acquires data while waiting for the trigger condition to occur.
When a trigger is detected, the oscilloscope continuously acquires enough
data to draw a waveform on the right of the trigger point.
The trigger mode of this series of oscilloscopes is edge trigging.
The edge trigging mode is to trigger on the trigger electrical level of the edge of
