Owon HDS200 Series User Manual

35
Characteristics
Description
Trigger displacement
According to Record length and time
base
Edge trigging
Slope
Rising edge, falling edge
The output of the probe compensator:
Characteristics
Description
Output voltage
(typical)
3.3Vpp, High-Z
Frequency
(typical)
Square wave 1 kHz (±1%)
Multimeter
Characteristics
Description
Digital display
20,000 readings
Measurement type
Voltage, current, resistance, capacitance, on/off,
diode
Maximum lnput voltage
AC : 750V DC : 1000V
Maximum lnput current
AC : 10A DC : 10A
Basic
function
Range
Minimum
resolution
Accuracy
DC voltage
200.00mV
0.01mV
±(0.3%+10dig)
2.0000V
0.1mV
±(0.3%+5dig)
20.000V
1mV
200.00V
0.01V
1000.0V
0.1V
AC voltage
[1]
200.00mV
0.01mV
±(0.8%+10dig)
2.0000V
0.1mV
20.000V
1mV
200.00V
0.01V
750.0V
0.1V
±( 1%+10dig)
frequency range：40Hz-1000Hz
DC current
200.00mA
0.01mA
±(0.8%+10dig)
10.000A
1mA
±(2.5%+10dig)
Overload protection:
mA function: self-healing fuse 400 mA/250 V; Ampere functio
n: 10A/600 V, D5.2*20, fast-acting fuse
