Owon HDS200 Series User Manual

36
Basic
function
Range
Minimum
resolution
Accuracy
AC current
[1]
200.00mA
0.01mA
±( 1%+10dig)
10.000A
1mA
±( 2.8%+10dig)
frequency range：40Hz-1000Hz
Overload protection:
mA function: self-healing fuse 400 mA/250 V; Ampere functio
n: 10A/600 V, D5.2*20, fast-acting fuse
Resistance
200.00Ω
0.01Ω
±(0.8%+10dig)
2.0000kΩ
0.1Ω
±(0.8%+5dig)
20.000kΩ
1Ω
±(0.8%+3dig)
200.00kΩ
10Ω
2.0000MΩ
0.1kΩ
20.000MΩ
1kΩ
±( 1%+3dig)
100.00MΩ
0.01MΩ
±( 5%+10dig)
Capacitance
[1]
20.000nF
1pF
±(3.0%+10dig)
200.00nF
10pF
2.0000μF
0.1nF
20.000μF
1nF
200.00μF
10nF
2.0000mF
0.1uF
Others
On/Off test
√ (<50Ω)
Diode test
√(<0-2V)
Auto range
√
TRMS
√
[1] When measuring AC voltage/current or capacitance, accuracy guarantee range is 5% to
100% of the range.
Arbitrary Waveform Generator (Optional)
Characteristics
Description
Waveform Frequency
Sine
0.1Hz~25MHz
Square
0.1Hz~5MHz
Ramp
0.1Hz~1MHz
Pulse
0.1Hz~5MHz
EXP
0.1Hz~5MHz
Sampling
125MSa/s
Amplitude(50Ω)
0.01Vpp ~ 2.5Vpp

Owon HDS200 Series Specifications

General

Brand	Owon
Model	HDS200 Series
Category	Test Equipment
Language	English
