Owon HDS200 Series User Manual

34
Characteristics
Description
Waveform
interpolation
(Sinx)/x
Sweep speed range
(S/div)
HDS242(S)
HDS272(S)
5ns/div - 1000s/div,Stepping
in the 1-2-5 way
HDS2102(S)
2ns/div - 1000s/div,Stepping
in the 1-2-5 way
Time base accuracy
±100 ppm
Record length
8K or 4K optional
Vertical
Sensitivity
(Volt/div) range
10 mV/div～10 V/div
Displacement range
±6 div
Analog bandwidth
HDS242(S)
40 MHz
HDS272(S)
70 MHz
HDS2102(S)
100 MHz
Single bandwidth
Full bandwidth
Low frequency
response
(AC coupling, -3dB)
≥10 Hz
Rise time
(typical on BNC)
HDS242(S)
≤ 8 ns
HDS272(S)
≤ 5 ns
HDS2102(S)
≤ 3.5 ns
DC gain accuracy
3%
Measurement
Cursor
ΔV, ΔT
Automatic
Period, Frequency, Mean, PK-PK,
Max, Min, Amplitude
Trigging
Source
CH1, CH2
Type
Edge
Coupling
DC, AC
Trigger type
Auto, normal, single
Trigger electrical
level range
±4 divs from the center of the screen
Trigger electrical
level accuracy
±0.3 div
