Save Settings
Press the Save key to enter the save function menu. By operating the save
function menu, oscilloscope settings, reference waveforms, and files can be
stored.
⚫ Settings
Any setting can be saved inside the oscilloscope, and restore settings can also
be called.
The description of Setting menu is as follows:
Save the current parameter settings of the
oscilloscope to the internal memory.
Call the settings saved in the current storage
location.
⚫ Reference Waveform
The actual waveform can be compared with the reference waveform to find out
the difference. Press the Save key to enter the save function menu, and press
F2 to select the reference waveform to enter the reference waveform menu.
The description of the Reference Waveform menu is as follows:
Select the reference waveform to be saved.
Call or close the waveform of the current target
address in the internal memory. When it displays
"On", if there is a stored waveform at the current
