Select LAN Set in the left menu. In the bottom menu, set the Type item as
WIFI-STA, and select Set in the bottom menu.
(2) In the right menu, select SSID, a keyboard will pop up. Input the name of the Wi-Fi
hotspot. You can turn and push the M knob, or touch the keyboard (if the LCD is
touchscreen).
(3) In the right menu, select Encryption, push to set the Encryption type of the Wi-Fi
hotspot. Open type needs no password. WEP or WPA type need to input the
password. In the right menu, select Password, use the keyboard to input the Wi-Fi
hotspot password.
(4) In the right menu, select IP:PORT, Turn the M knob to set the PORT. Here, we set it
to 3000.
(5) After setting, select ON in the Status menu. The value of IP is displayed in IP:PORT
menu. Here IP is 10.1.1.126. A changing icon
appears on the top right of the
screen.
(6) Select Save set in the bottom menu to save current settings.
(7) Set the network parameters of the computer. Set IP in the computer, the first three
bytes is same as the IP in the oscilloscope, the last byte should be different. Here, we
set it to 10.1.1.123. The Default gateway and Subnet mask should be set according to
the router.
