Owon XDS3204E - How to Operate the Function Menu; How to Implement Sampling Setup

4.Advanced User Guidebook
Display
Format
Binary
Decimal
Hex
ASCII
Set the display format of the bus.
EventTable
ON
OFF
Select "ON" to display the event table.
Save
EventTable
If a USB storage device is currently connected to the
instrument, save the event table data
in a .csv
(spreadsheet) formatted file on the external USB storage
device.
How to Operate the Function Menu
The function menu control zone includes 8 function menu buttons: Measure, Acquire,
Utility, Cursor, Autoscale, Save, Display, Help and 3 immediate-execution buttons:
Autoset, Run/Stop, Single.
How to Implement Sampling Setup
Push the Acquire button, Acqu Mode, Length, PERF Mode (only for XDS3000-A
series) and Intrpl is shown in the bottom menu.
The description of the Acqu Mode menu is shown as follows:
Function Menu
Setting
Description
Acqu
Mode
Sample
Normal sampling mode.
Peak Detect
Use to capture maximal and minimal
samples. Finding highest and lowest points
over adjacent intervals.
It is used for the
detection of the jamming burr and the
possibility of reducing the confusion.
Average 4, 16, 64, 128
It is used to reduce the random and don't-care
noises, with the optional number of averages.
The description of the Record Length menu is shown as follows:
Function Menu
Setting
Description
Length
1000
Choose the record length
(For XDS3102AP/XDS3202A, 40M is
available on both single CH and double CH)
10K
100K
1M
10M
20M
