11.Technical Specifications
Performance Characteristics
Instruction
XDS3202E
XDS3202
XDS3302
≥ 2 mV 2%
DC accuracy (average)
Delta Volts between any two averages of
≥16 waveforms acquired with the same
scope setup and ambient conditions (△V):
±(3% rdg + 0.05 div)
Waveform inverted ON/OFF
Measurement
Cursor
△
V,
△
T,
△
T&
△
V between cursors,
auto cursor
Automatic
Period, Frequency, Mean, PK-PK, RMS,
Max, Min, Top, Base, Amplitude, Overshoot,
Preshoot, Rise Time, Fall Time, +Pulse
Width, -Pulse Width, +Duty Cycle, -
Duty
Cycle, Delay A→B , Delay A→B
, Cycle
RMS, Cursor RMS, Screen Duty, Phase,
+Pulse Count, -Pulse Count, Rise
Edge
Count, Fall Edge Count
, Area, and Cycle
Area.
Waveform Math
＋
,
－
, *, / ,FFT, FFTrms, Intg, Diff, Sqrt,
User Defined Function, digital filter (low
pass, high pass, band pass, band reject)
Decoding Type
(optional)
RS232, I2C, SPI, CAN
Waveform storage 100 waveforms
Lissajous
figure
Bandwidth
Full bandwidth
Phase
difference
±3 degrees
Communication
port
Standard
USB, USB Host (USB storage）；Trig Out(P/F)；LAN port
Optional
VGA port and AV port
Counter Support
Trigger
Performance Characteristics
Instruction
Trigger level range
Internal ±5 div from the screen center
EXT
±2 V
EXT/5
±10 V
Trigger level
Accuracy (typical)
Internal
±0.3 div
EXT
± (10 mV + 6% of Set Value)
EXT/5
± (50 mV +6% of Set Value)
143
