11.Technical Specifications
Trigger
displacement
According to Record length and time base
Trigger Holdoff
range
100 ns – 10 s
50% level setting
(typical)
Input signal frequency ≥ 50 Hz
Edge trigger slope Rising, Falling
Video Trigger
Modulation
Support standard NTSC, PAL and SECAM
broadcast systems
Line number range 1-525 (NTSC) and 1-625 (PAL/SECAM)
Pulse trigger
Trigger condition
Positive pulse
：＞
,
＜
,
＝
Negative pulse
：＞
,
＜
,
＝
Pulse Width range
30 ns to 10 s
For XDS3102AP/XDS3202A, the range is
8 bits mode
2 ns to 10 s
12 bits mode
4 ns to 10 s
14 bits mode
20 ns to 10 s
Slope Trigger
Trigger condition
Positive pulse
：＞
,
＜
,
＝
Negative pulse
：＞
,
＜
,
＝
Time setting
30 ns to 10 s
For XDS3102AP/XDS3202A, the range is
8 bits mode
2 ns to 10 s
12 bits mode
4 ns to 10 s
14 bits mode
20 ns to 10 s
Runt Trigger
Polarity
Positive, Negative
Pulse Width
Condition
>, =, <
Pulse Width Range
30 ns to 10 s
For XDS3102AP/XDS3202A, the range is
8 bits mode
2 ns to 10 s
12 bits mode
4 ns to 10 s
14 bits mode
20 ns to 10 s
Windows Trigger
Polarity
Positive, Negative
Trigger Position
Enter, Exit, Time
Windows Time
30 ns to 10 s
For XDS3102AP/XDS3202A, the range is
8 bits mode
2 ns to 10 s
12 bits mode
4 ns to 10 s
14 bits mode
20 ns to 10 s
Timeout Trigger
Edge Type
Rising, Falling
Idle Time
30 ns to 10 s
For XDS3102AP/XDS3202A, the range is
8 bits mode
2 ns to 10 s
12 bits mode
4 ns to 10 s
14 bits mode
20 ns to 10 s
