8.Communication with Android Device via Wi-Fi (Optional)
(6) Select Save set in the bottom menu to save current settings.
(7) In Android device, enter the Wi-Fi settings, select the oscilloscope access point to
connect, enter the set password.
(8) In Android device, launch the application.
(9) Click connect on the left.
(10) Set IP and Port to the same value as the setting in the oscilloscope. Click Confirm
to connect. Click History to recall the history settings.
125
