4.Advanced User Guidebook
type is CAN, CH1 trigger level is -126 mV.
CAN Trigger menu list:
Set vertical channel bus type as CAN trigger.
Select CH1 as the trigger source.
Select CH2 as the trigger source.
Actual CAN_H bus signal.
Actual CAN_L bus signal.
Transmission signal on the CAN signal line.
Received signal on the CAN signal line.
Turn the M knob (or tap on in touchscreen) to set
the Sample point, which is a point within a bit’s time. The
oscilloscope samples the bit level at this point. “Sample
point” is represented by the percentage of “the time from
the start of the bit’s time to the sample point time” in the
“bit’s time”. The range is 5% to 95%.
Turn the M knob to select from the Baud list on the left.
Turn the M knob (or tap on in touchscreen) to set
the Baud. The range is 10,000 to 1,000,000.
Tip: You can select the nearest value in Common Baud,
and then adjust it in this menu.
Trigger on the start frame of the data frame.
Trigger on the selected frame.
Select Standard or Extended.
Use the M knob and Direction
key on the front panel to set.
Set the number of bytes with the
M knob. The range is 1 to 8.
Set the data with the M knob
and Direction key on the front
panel.
Select Standard or Extended.
To Next Page
