Owon XDS3204E User Manual

4.Advanced User Guidebook
57
Configure
Common
Baud
Turn the M knob to select from the Baud list on the left.
Custom
Baud
Turn the M knob (or tap on in touchscreen) to set
the Baud. The range is 50 to 10,000,000.
Tip: You can select the nearest value in Common Baud,
and then adjust it in this menu.
Data Bits
Set the data width of each frame to match the signal. It
can be set to 5, 6, 7 or 8.
Parity
set the even-odd check mode to match the polarity used
by the signal.
Display
Format
Binary
Decimal
Hex
ASCII
Set the display format of the bus.
EventTable
ON
OFF
Select "ON" to display the event table.
Save
EventTable
If a USB storage device is currently connected to the
instrument, save the event table data in a .csv
(spreadsheet) formatted file on the external USB storage
device.
2. I2C Decoding
To decode I2C signal:
(1) Connect the clock line (SCLK) and the data line (SDA) of the I2C signal to the
Signal Input Channels of the oscilloscope.
(2) Adjust to the proper time base and voltage division.
(3) In trigger menu, select Bus trigger, and select bus type as I2C, set parameters
based on the characteristics of the signal, trigger the signal correctly and obtain
stable display. Refer to "I2C Trigger" on page 52.
(4) Push the Decode button on the front panel. Select bus type as I2C. set parameters
based on the characteristics of the signal. When the parameters are set correctly,
the information carried by the signal will be displayed.
Tip: If there are repetitive menu items in both trigger menu and decoding menu, you
can set anyone of them, the other will be changed synchronously.
Decoded information interpretation:
Information
Abbreviation
Background
Read Address
R, Read, or do not display
Green
Write Address
W, Write, or do not display
Green
