arrive as the sequence 01001000 in binary representation, will be decoded as the
reversed sequence 00010010.
SPI Decoding menu list:
Set bus type of decoding as SPI.
Select the clock edge to match the signal, sample the
SDA data on the rising or falling edge of the clock.
Set the minimum time that the clock (SCL) signal must
be idle before the oscilloscope starts to search for the data
(SDA) on which to trigger. The range is 30 ns to 10 s.
Set the data width of each frame to match the signal. It
can be set to any integer between 4 and 32.
Select LS First or MS First to match the signal.
Set the display format of the bus.
Select "ON" to display the event table.
If a USB storage device is currently connected to the
instrument, save the event table data in a .csv
(spreadsheet) formatted file on the external USB storage
device.
4. CAN Decoding
To decode CAN signal:
(1) Connect the CAN signal to the Signal Input Channel of the oscilloscope.
(2) Adjust to the proper time base and voltage division.
(3) In trigger menu, select Bus trigger, and select bus type as CAN, set parameters
based on the characteristics of the signal, trigger the signal correctly and obtain
stable display. Refer to "CAN Trigger" on page 54.
(4) Push the Decode button on the front panel. Select bus type as CAN. set
parameters based on the characteristics of the signal. When the parameters are set
correctly, the information carried by the signal will be displayed.
Tip: If there are repetitive menu items in both trigger menu and decoding menu, you
can set anyone of them, the other will be changed synchronously.
Decoded information interpretation:
