Owon XDS3204E User Manual

4.Advanced User Guidebook
79
Each parameter name is a case-sensitive string of 4 bytes. The parameter value is at least 4 bytes.
1.Format description of the file header:
1) HEAD
Parameter name
Meaning
Value
Comment
HEAD
Header size
4 bytes int
2) TYPE
Parameter name
Meaning
Value
Comment
TYPE
Model
12 bytes char
3) BYTE
Parameter name
Meaning
Value
Comment
BYTE
Data length in bit
4 bytes int
4) SIZE
Parameter name
Meaning
Value
Comment
SIZE
File size
4 bytes int
Used to check the file
integrity
5) VOLT
Parameter name
Meaning
Value
Comment
VOLT
Voltage division,
divided by 400 is
ADC resolution.
(When the source is
CH1&CH2, it is CH1
voltage division.)
4 bytes float
The value indicates voltage
(the unit is mV), such as 200
mV.
6) SAMP
Parameter name
Meaning
Value
Comment
SAMP
Sample rate
4 bytes float
The unit is Sa/s.
7) ADCB
Parameter name
Meaning
Value
Comment
ADCB
ADC bit, ADC
resolution
4 bytes int
8-bit or 12-bit
8) CHAN
Parameter name
Meaning
Value
Comment
CHAN
Number of channels
4 bytes int
1 or 2
9) VOL2
Parameter name
Meaning
Value
Comment
VOL2
Voltage division,
divided by 400 is
ADC resolution.
(When the source is
CH1&CH2, it is CH2
voltage division.)
4 bytes float
The value indicates voltage
(the unit is mV), such as 200
mV.
2.Data
