Chapter 9: Transmission Assembly
23.60
OXY0247 - Main
Gear Bushing
OXY2 support two kind of
servo dimension, use specific
main gear bushing spacer
for Servo type B.
Main Gear 110T-55T pulley
Assembly
(Box 2/Bag 3)
OXY2 Tail Assembly
Tail System And Main Gear Installation
Insert Tail
Assembly as shown
Servo Type B
page 20
Before next assembly step check carefully
Tail Belt assembly position as shown.
Important Note:
The Main Gear come
factory pre assembled.
It is ready to use.
To Next Page
