Chapter 13: Flybarless Installation
Double - Side Tape
(Box 2/Bag 4)
The FBL system can be
installed at the bottom or
top of the boom clamp.
We suggest to use the
bottom for easy wiring
and servo removal.
For extra FBL support we
suggest to add Electronic
Hook and Loop as shown.
Flybarless Unit
Position 1
page 27
Flybarless Unit
Position 2
