Head Assembly
2 x M1.6x6 Hex
Cap Screw
M2x8 Hex
Cap Screw
All Screw in this step
need add loctite,
don't over tighten.
page 25
Swash Plate
Assembly
Main Rotor Assembly step 1
Chapter 11: Main Rotor Assembly
Main Rotor Assembly step 2
