Oxy Heli OXY4 - Page 10

MR63_ZZC - 3X6X2.5 Radial Bearing
OXY0727 - 3x4x2.3 Bushing
OXY0674 - Tensioner Adapter
OXY0725-Pulley Guide Belt
Tail Belt Tensioner Assembly
( Box 3 / Bag 5 )
Tail Belt Crank Support Assembly
( Box 3 / Bag 5 )
Tail Belt Crank Assembly
( Box 3 / Bag 5 )
Important Note:
This part, for tuning reasons,
comes factory pre assembled,
it ready to use
2xMF682ZZ-2X5X2.3
Flange Bearing
OXY0673-Bell Crank Support
Chapter 6: Tail Assembly
Important Note:
This part, for tuning reasons,
comes factory pre assembled,
it ready to use
Important Note:
This part, for tuning reasons,
comes factory pre assembled,
it ready to use
page 9
OXY0724-Tail Bell Crank
OXY0057-Tail Pin Screw
