Oxy Heli OXY4 - Page 13

Chapter 6: Tail Assembly
SCM3x3-
Set Screw M3x3
2 x TBEM2X6 - M2X6
Button Screw
Tail Bell Crank Assembly
2 x M2X6 Button Screw
Note: Line up the
holes, so the set
screw seats correctly
into tail shaft lock hole.
page 12
OXY0717 - PL
Tail Servo Support
(Box 3 / Bag 7 )
Note: don't install any screw
