4.7.1 Connect the thermostat
When the IntrCooll® is controlled by a thermostat follow the documentation of
the thermostat for a correct installation.
Before installation see the communication requirements on page 37 for more
information.
IntrCooll® connector for communication (RS485) with thermostat is J17:
- 2 wires used for RS485 communication.
- 2 wires for 24 VDC power supply.
4.8 Step 7. Finish the installation
To nish the installation:
1. Check the following:
• No tools and peripherals remain in the interior of the IntrCooll®.
• All components are in place.
• All tubes and hoses are (re)connected.
• All electrical components are (re)connected.
2. Place all covers on the unit.
4.8.1
Step 7b. Fill-out installation checklist
Model:
Serial number:
Installation date:
Location address:
Installer:
48
