oxycom IntrCooll Std. - Support Frame (Not Provided); Ducting

1 Breather vent pipes or sewer pipes 5000 mm
2 Solid heater ue pipes 3000 mm
3 3Walls or air blocking obstacles 600 mm
Exhaust air openings 10 000 mm
Neighboring residences Local regulations
TV antenna 5000 mm
3.2 Support frame (Not provided)
Note
When not used in combination with a Flashing Kit (optional) on page 23 or a
Natural Ventilator module (optional), the contractor shall provide a support
frame for the IntrCooll®.
As an option a support frame can be ordered at Oxycom:
- Article no. 5301251, support frame for IntrCooll® Std.
- Article no. 5301305, support frame for IntrCooll® Plus
Refer to the accessories brochure for more information on the optional support
frame.
If the contractor provides a support frame, Oxycom recommends the use of a
support frame with the following specications:
- The prole for the welded frame is galvanized steel "L".
- prole of 40 mm x 40 mm x 3 mm.
- The support frame should have a loading capacity of at least the wet weight
of the unit.
- Unit must be placed/positioned 100% level. If not level, water might leak into
ducting.
Minimum height:
- Std.: 400 mm.
- Plus: 500 mm.
22
