Install the IntrCooll®
Version 1.3, 2021-12-14 49
1
2
3
4
5
1 Delivery of the crate and transport to the installation site YES NO Reference
A Is there a place indoor where the crated equipment can be stored
temporarily?
o o
Handling and storage
B Is there a fork-lift truck or any other lifting device available with
proper lifting gear/ropes according to manual?
o o
Transport
Remarks:
2 Installation requirements YES NO
A Minimum free space for 1 side of 600 mm?
o o
Space
requirements on page 20
B Minimum free space for 3 or more sides of 1000 mm?
o o
Space
requirements on page 20
C There are no obstacles (i.e exhaust vents/fans, sewer pipe vents)
near equipment.
o o
Location
requirements on page 20
D If the unit is placed/elevated more than 1.5 m above roof/oor, a
service platform with minimum free space (see 2.A and 2.B) is
provided?
o o
Remarks:
3 Equipment installation YES NO
A Support frame(s) for IntrCooll®
(not applicable for optional Flashing Kit or Natural Ventilator
module)
o o
Support frame (Not provided)
B Equipment will be placed level (to prevent water leakage in
ducting)
o o
Roof transit for
ducting on page 26
C Watertight roof transit for ducting
o o
Roof transit for
ducting on page 26
D Water tight roof transit for cabling/water pipes
o o
Roof transits for cabling /
plumbing on page 26
E Roof beam supports are calculated/constructed such that they can
hold weight of IntrCooll® in operation (wet)
o o
Roof beam
supports on page 24
F Ducting diameter/dimensions according to specications?
o o
Opening and curb on page 24
