G Minimum free space for 3 or more sides of 1000mm?
o o
Space
requirements on page 20
H Modulating exhaust air vents/fans including cabling are accounted
for?
(might require roof support beams as well)
o o
Exhaust air on page 27
Remarks:
4 Electrical specications YES NO
A Electrical supply phases/voltage/frequency meets equipment
requirements?
o o
Electrical
requirements on page 36
B External power supply fuse for each unit
o o
Power supply fuse on page 36
C Power isolating (padlock) switch provided for each unit (preferable
on the roof near the equipment)
o o
Power isolating
switch on page 36
D Power supply cable meets specications and local regulations
o o
Electrical
connections on page 47
E Power supply cable connected correctly?
o o
Electrical
connections on page 47
F Power supply cable of equipment (maximum 1.5m) will be
connected to an external terminal box, so that equipment can
easily be disconnected, when necessary.
o o
G Equipment will be earthed.
o o
Electrical
connections on page 47
H Main power outlet for service / maintenance available on the roof /
in close proximity to equipment?
o o
Mains power outlet on page 37
I Correct ow regulator cap mounted? 50 Hz standard, exchange if
necessary for 60 Hz use.
o o
Step 5. Flow regulator
cap on page 45
Remarks:
5 Communication specication YES NO
A Is thermostat ordered for each IntrCooll®? Not applicable if
connected to optional OxyConnect gateway or BMS system.
o o
Communication
requirements on page 37
B Thermostat mounted on a suitable spot?
o o
Thermostat control on page 37
