Ozito ECS-355 - Chain Bar Oil

1
NOTE: ONLY USE OIL THAT IS EXPRESSLY LABELLED
“CHAIN BAR OIL”.
2. CHAIN BAR OIL
1.Removethechainbaroilcapandllthetank.ChainBarOilTank
Capacity:125ml
2.Retcapandclean
anyoilspillage.
3.Alwayslltheoiltankwhenthe
oil level is below the minimum
mark on the oil level window.
4.Tocheckthelubricatingsystem,switchonthechainsawandhold
itwiththeguidebarandchainabovesomelightcolouredpaper
suchasnewspaper.Asteadilyincreasingstaincausedbyoilspray
shows the lubricating system is working.
WARNING!: NEVER START WORK UNLESS THE
CHAIN AND BAR ARE LUBRICATED.
NOTE: THE CHAIN SHOULD BE ADJUSTED BEFORE
FIRST USE, AGAIN AFTER 2-3 MINUTES OPERATION
AND RECHECKED AND ADJUSTED IF NECESSARY
AFTER EACH FURTHER 30 MINUTES OF USE. TAKE
CARE NOT TO OVER TENSION THE CHAIN.
5. Adjust the chain
tensioningscrew(C)
untilthebolt(A)tsinto
the hole in the guide bar.
6.Fitthesidepanelbackontothe
chainsawandreplacethebar
securingnutngertightonly.
7.Adjustthetensiononthechainusingthechaintensionscrew(C).
The tension is correct when the
chain can be pulled 3mm away
from the guide bar when using
your nger and thumb.
Do not over-tighten as this will
reduce the life of the chain and
guide bar.
8.Tightenthebarsecuringnut. 9.Replacethebarsecuringnut
cover.
A
C
3mm gap is
the ideal tension
NOTE: CHAIN BAR OIL MAY LEAK IF THE TOOL IS
LEFT FOR LONG PERIODS. THIS IS NORMAL. IF THE
TOOL IS TO BE LEFT UNUSED FOR AN EXTENDED
TIME, DRAIN THE OIL FROM THE TOOL. REFILL
BEFORE USE.
