PAC SWI-CP2 - Manually Mapping SWC Buttons; SWC Programming Steps; Radio Function Mapping Order

SWI-CP2
Universal Steering Wheel Control Retention Interface
TM
Steering Wheel Control Interface
P ifi A C ti
Rev. 051617
Page 3
Copyright © 2017. All rights reserved. PAC is a Power Brand of AAMP Global.
PAC-audio.com
Alpine JVC Kenwood Clarion
Other

Pioneer Sony Fusion
1 Volume + Volume + Volume + Volume + Volume + Volume + Volume + Volume +
2 Volume - Volume - Volume - Volume - Volume - Volume - Volume - Volume -
3 Mute Mute Mute Mute Mute Mute Mute Mute
4 Preset + Source Source Source Preset + Preset + Preset + Source
5 Preset - Track + Play Search + Preset - Preset - Preset - Track +
6 Source Track - Track + Search - Source Source Source Track -
7 Track + Band / Disc + Track - Band Track + Track + Track + Audio
8 Track - Preset / Disc - Disc / FM + Send / End Track - Track - Track - Power
9 Power Select Disc / AM - Send Band Band Band
10 Enter/Play Attenuation Answer End
Answer

Phone Menu
Reject Call / Source
(Bluetooth
equipped radios
only)
11 Band / Program Phone Receive Voice Dial VR
End

Answer Call Answer / End Call
12 Receive Phone Reject On Hook
PTT

End Call VR
13 End Voice Dial Off Hook VR
14 VR Power
Mute (Multimedia
units only)
15 Preset +
 - Advent, Boyo, Dual, Lightning Audio, Jensen, Rockford Fosgate & Visteon  - Jensen & Advent ONLY
PLEASE NOTE: This section only applies to button programming in manual programming mode. If you are using the CP2
LQPDQXDOFRQ¿JXUDWLRQPRGHVSHFL¿FYHKLFOHGLSVZLWFKVHWWLQJVDQGZLVKWRUHDVVLJQEXWWRQIXQFWLRQVSOHDVHIROORZ
the “SWC Button Re-assignment Procedure” on page 4.
Please read each of the following steps to familiarize yourself with the process before beginning. The interface must be programmed
LQWKHVSHFL¿FRUGHUVKRZQLQWKHFKDUWEHORZ
1. Turn the key to the ignition position. The LED will illuminate red.
2. Press and hold the programming button on the side of the interface until the LED illuminates green. Release the
programming button.
3. Within 7 seconds, press the button that is to be learned on the steering wheel. At this point you have two options:
a. For short press functionality: Hold the button on the steering wheel until the LED changes from green to red.
Release the button.
b. For long press functionality: &RQWLQXHWRKROGWKHEXWWRQXQWLOWKH/('ÀDVKHVEHWZHHQUHGDQGDPEHURQFH
Release the button.
4. If you need to program more buttons, repeat step 3 for each additional audio function on the steering wheel.
5. If you come across a function in the chart that your steering wheel does not have, or you do not want to program, press
and release the program button on the side of the interface to skip that function. The LED will turn off then back on when
the skip has been done successfully.
6. 2QFHSURJUDPPLQJLVFRPSOHWHGZDLWVHYHQVHFRQGV7KH/('ZLOOÀDVKJUHHQWLPHVLQGLFDWLQJWKHHQGRISURJUDPPLQJ
7. Test the interface for proper functionality. Whenever a SWC button is pressed the LED on the interface should blink green.
If any function does not work, repeat the programming steps.
Manually Mapping the SWC Buttons
Radio Function Mapping Order
