7HVWLQJ9HUL¿FDWLRQ
1. Turn the ignition on. The red LED on the interface will turn on & the +12v accessory output wire will turn on.
2. 9HULI\WKDWDOO6:&DUHIXQFWLRQLQJSURSHUO\7KHJUHHQ/('ZLOOÀDVKHDFKWLPHLWVHHVDVWHHULQJZKHHOEXWWRQSUHVVHG
3. Turn off the vehicle & remove the key. In vehicles equipped with retained accessory power (RAP) the accessory output and
the red LED will remain active & keep the radio on for 10 minutes unless the driver side door is opened. In vehicles that do not
support RAP the LED and accessory output will shut off when the key is switched or removed from the ignition.
3/($6(
127(7KLVVHFWLRQRQO\DSSOLHVWREXWWRQUHDVVLJQPHQWZLWKLQDFRQ¿JXUDWLRQ,I\RXDUHXVLQJWKH&3LQ
manual programming mode (all vehicle dipswitches up) please refer to the “Manually Mapping the SWC Buttons” section
on page 3
If you wish to re-assign the SWC functions or utilize short press long press dual command functionality you will need to follow the
steps outlined in this section. Please read each of the following steps to familiarize yourself with the process before beginning.
7KHLQWHUIDFHPXVWEHSURJUDPPHGLQWKHVSHFL¿FRUGHUVKRZQLQWKHFKDUWEHORZ

1. Turn the key to the ignition position. The LED will illuminate red.
2. Press and hold the programming button on the side of the interface until the LED illuminates green. Release the
programming button.
3. Within 7 seconds, press the button that is to be learned on the steering wheel. The LED will turn red when the steering
wheel button is pressed. At this point you have two options:
a.
For short press functionality: Release the button on the steering wheel. The LED will change back to green.
b. For long press functionality: &RQWLQXHWRKROGWKHEXWWRQXQWLOWKH/('ÀDVKHVEHWZHHQUHGDQGDPEHU5HOHDVH
the button and the LED will change back to green.
4. If you need to program more buttons, repeat step 3 for each additional audio function on the steering wheel.
5. If you come across a function in the chart that your steering wheel does not have, or you do not want to program, press
and release the program button on the side of the interface to skip that function.
The LED will turn off and back on when
the skip has been done successfully.
6. 2QFHSURJUDPPLQJLVFRPSOHWHGZDLWVHYHQVHFRQGV7KH/('ZLOOÀDVKJUHHQWLPHVLQGLFDWLQJWKHHQGRISURJUDPPLQJ
7. Test the interface for proper functionality. Whenever a SWC button is pressed the LED on the interface should blink green.
If any function does not work, repeat the programming steps.
The SWC can always be restored to default settings by pressing and holding the programming button on the side of the interface
XQWLOWKH/('LOOXPLQDWHVJUHHQ5HOHDVHWKHSURJUDPPLQJEXWWRQWKHQZDLWVHFRQGVIRUWKH/('WRÀDVKWLPHV
SWC Button Re-assignment Procedure
Alpine JVC Kenwood Clarion
Other

Pioneer Sony Fusion
1 Volume + Volume + Volume + Volume + Volume + Volume + Volume + Volume +
2 Volume - Volume - Volume - Volume - Volume - Volume - Volume - Volume -
3MuteMuteMuteMuteMuteMuteMuteMute
4 Preset + Source Source Source Preset + Preset + Preset + Source
5 Preset - Track + Play Search + Preset - Preset - Preset - Track +
6 Source Track - Track + Search - Source Source Source Track -
7 Track + Band / Disc + Track - Band Track + Track + Track + Audio
8 Track - Preset / Disc - Disc / FM + Send / End Track - Track - Track - Power
9 Power Select Disc / AM - Send Band Band Band
10 Enter/Play Attenuation Answer End
Answer

Phone Menu
Reject Call / Source
(Bluetooth
equipped radios
only)
11 Band / Program Phone Receive Voice Dial VR
End

Answer Call Answer / End Call
12 Receive Phone Reject On Hook
PTT

End Call VR
13 End Voice Dial Off Hook VR
14 VR Power
Mute (Multimedia
units only)
15 Preset +
 - Advent, Boyo, Dual, Lightning Audio, Jensen, Rockford Fosgate & Visteon  - Jensen & Advent ONLY
Optional Programming Order
