6. Reconnect the vacuum line support bracket. Install a new
ty-wrap.
7. Reconnect the hose on the right of the heater assembly.
8. Reconnect the hose on the top of the heater assembly.
9. Reinstall the ground wire that is located on the left side of the heater
assembly.
Figure 44
Figure 45
Figure 46
Figure 47
