System Operations Manual
www.paceworldwide.com
Page 43 of 50
10. Reinstall the pick solenoid sensor.
11. Install the solenoid pick sensor cover and four screws.
12. Reconnect the pick solenoid wiring on the left side of the
heater assembly.
13. Reconnect the main heater wiring on the left side of the heater
assembly. It does not matter which one is attached to which.
14. Bring the heater cover up near the heater assembly.
Reconnect the wires on each side and tie them back to their
mounts. Be sure to pull the wires up taught so they do not
contact the heater.
Figure 48
Figure 49
Figure 50
