Pacific Scientific OC950 - Getting Started; Setting up the Hardware

2 Getting Started
Introduction This chapter provides a step-by-step introduction to creating a
new program. This procedure uses the minimum possible
equipment to run an unloaded motor and sets motor speed from a
PC’s serial port. It is strongly recommended that all first time
users go through this procedure to become familiar with the
OC950 and the 950IDE PC interface software before installing
the servo system in a machine.
2.1 Setting Up the Hardware
What you will
need
To go through this product introduction procedure you will need
the following items.
• SC900 Base Servo Drive
• OC950 Programmable Option Card
• Appropriate Brushless Motor with nothing attached to the
shaft
•
PC Running Windows 3.1 or Windows95/NT
•
950IDE Floppy Disk
•
Motor Power and Feedback Cables (J2, J3)
•
RS-232 Communications Cable (J51)
•
DB-25 Connector Mate (J4)
•
AC Power Line (J1)
MA950 2-1
