S1 Address table
(cont’d)
Address 1 2 3 4 5 6 7 8
240 On On On On Off Off Off Off
241 Off On On On Off Off Off Off
242 On Off On On Off Off Off Off
243 Off Off On On Off Off Off Off
244 On On Off On Off Off Off Off
245 Off On Off On Off Off Off Off
246 On Off Off On Off Off Off Off
247 Off Off Off On Off Off Off Off
248 On On On Off Off Off Off Off
249 Off On On Off Off Off Off Off
250 On Off On Off Off Off Off Off
251 Off Off On Off Off Off Off Off
252 On On Off Off Off Off Off Off
253 Off On Off Off Off Off Off Off
254 On Off Off Off Off Off Off Off
255* Off Off Off Off Off Off Off Off
* For RS-232 operation (factory default)
Procedure 1. Remove power from the SC950 servocontroller.
2. Refer to the table above to set the appropriate address.
3. Reconnect power to the SC950 servocontroller.
4. Repeat steps 1 through 4 for other SC950 units on the bus.
Make sure to give the other units unique addresses.
