Output Channel
Device Open Drain DMOS Transistor
Sink Capability 100 milliamperes
Drain-to-Source -
Impedance
5 ohms typical, 9.5 ohms maximum at 125° C
Connector 25 Contact Female D-subminiature
User +5V Power
(OC950 J51-4, J52-25 and SC900 J4-25)
Output Voltage
5 Volts ± 5%
Output Current 200 milliamperes, Maximum
Note: Output current is the combined current of all three
connection points.
OC950 J53 (Optional) PacLAN
Data Rate 2.5 MBaud
Termination
Impedance
93 ohms
Cable Type coaxial, RG62U
Maximum Bus
Segment Length
305 meters
Maximum
Stations/Segment
8
Connector Standard BNC
NVRAM - Program Memory
Data Retention 10 Years
