Wiper Power
The last wire of the ACCESSORY section is wire intended for windshield wipers.
If you do not have a wiper system, this wire can be used to power some other
accessory so long as the max amperage does not exceed 10 amps. This wire is:
Black/Yellow: 16 gauge wire, printed [ACCESSORY SECTION] #905 TO WIPER
POWER/ACCESSORY (IGN. POWER), this wire will supply switched ignition power to
the wiper motor/switch from the 15 amp WIPER/TURN fuse on the fuse block.
Since we at Painless have no idea what system or what speed wiper your
particular install is using, we only provide power to the system. It will be up to you the
installer to add additional wires from the wiper switch to the wiper motor for correct
operation.
“GROUND”
A single wire can be found in this harness that is intended to connect to a clean
chassis ground source. This wire will have a section label reading “GROUND”, it is:
Black: 10 gauge wire, printed #969 GROUND, this wire will supply a ground source to
the ground wires as it is is part of the ground circuit of the Painless harness. This wire
can be seen in the Ground Schematic on page 14.
Route the Ground wire to a clean chassis ground source. Grounds were
explained on page 12 of the first manual.
If the fuse block was mounted to a metal surface, the bolts holding the fuse
block in place would be an ideal place.
Cut the wire to length, strip ¼” of insulation from the wire and using a ring
terminal from the parts kit, connect this wire to a clean chassis ground source.
NOTES:
