Planning connections beforehand will give you a better understanding of what
needs to be routed, if any additional wires may need to be added, and how to make the
best use of any extra circuits provided in the Painless harness.
CONTENTS OF THE PAINLESS WIRE HARNESS KIT
Refer to the Contents Figure (below) to take inventory. See that you have
everything you’re intended to have in this kit. If you find that anything is missing or
damaged, please contact the dealer where you obtained the kit or Painless
Performance at (800) 423-9696.
The Painless Wire Harness Kit should contain the following:
Power Supply Harness Harness, with the fuse block pre-installed
Output supply harness
3 rolled wires: Red, Black/Yellow, and Black/Red
Parts Kits: (1) insulated loose piece terminals kit (1) un-insulated terminal kit
3 bag kits: Alternator bag, heat shrink bag, a bag w/ zip ties and other parts
This manual: parts #1 and #2
CONTENT FIGURE- All of the parts in the Painless kit
