In the event that a toggle/rocker switch is being used without a relay, make sure
the amperage of the component you are powering does not exceed the capabilities of
the switch. Switch failure will occur.
Fuse Block Mounting
Locate the harness with the fuse block pre-installed.
To begin mounting the fuse block, you will need to find a suitable location that will
allow easy access in the event you have to replace a fuse, and also allow enough
length for the wires to reach things like the ignition switch, headlight switch, etc. Make
sure this area in out of the elements and in an area that will not get wet.
Mount the fuse block to the mounting location in one of the following 2 ways:
1) Drilling holes using a ¼” drill bit and using the four bolts, nuts and washers
supplied
2) Using the four self tapping screws and a ¼” nut driver on a drill.
