HEADLIGHT SECTION CONNECTIONS
The HEADLIGHT SECTION of this Painless Harness includes all power and
ground wires needed to properly hook up both driver and passenger side headlights,
and left and right front turn & park/marker lights. There is also a power wire from the
fuse block mounted horn relay to power a horn. All wires in the Headlight Section can
be seen in the Headlight Section Schematic on page 30.
Left/Driver Side Headlamp
Your first connection in the Headlight Section will be the Left/Driver side
Headlamp. Three wires make up the connection to the Left Headlamp, they are:
Black/Green: 14 gauge wire, printed [HEADLIGHT SECTION] #908 TO DRIVER
HEADLIGHT HIGH BEAM, this wire will provide power to the high beam filament of the
head lamp. This wire goes into a splice with a wire going to the right headlamp and also
to a wire going to the high beam indicator in the dash and to the dimmer switch. This
wire will have power when the dimmer switch is in the high beam position and the
headlight switch is in the headlight ON position.
Black/Tan: 14 gauge wire, printed [HEADLIGHT SECTION] #909 TO DRIVER
HEADLIGHT LOW BEAM, this wire will provide power to the low beam filament of the
head lamp. This wire goes into a splice with a wire going to the right headlamp and also
to a wire going to the dimmer switch. This wire will have power when the dimmer switch
is in the low beam position and the headlight switch is in the headlight ON position.
Black: 14 gauge wire, printed [HEADLIGHT SECTION] #969 DRIVER HEADLIGHT
GROUND , this wire provides a ground source for the headlamp. This wire is tied into
the integrated ground circuit and can be seen in the Ground Schematic on page 14.
