Both diagrams accomplish the same task, using the black/brown #914
ALTERNATOR EXCITER wire to provide a switched power source and a
resisted power source to the 2 wires of a CS-130D alternator
pigtail/connector when a charge indicator light is NOT being used. Pick the
method that easiest for you to understand.
