Sensor Technology
4
Subject to change without notice
27
4.3 Sensor B 4
Sensor Position/Name Adjustment
B4 Speed counter flat belts The slot disc must rotate centrally in the
sensor’s slot. N.B. Bearing damage to the slot
disc shaft will result in destruction of the
sensor.
B4
