5
Pneumatics
40
Subject to change without notice
5.3 Valve manifold
Manual operation:
The valves in the valve manifold (V 1 – V 7) can be switched over to manual operation with a
snap-in switch, which means that every cylinder can be operated manually.
NB: When starting the machine all switches must be engaged in automatic mode.
The main valve (V 9) can be operated by a black button situated on the top.
5.4 Deflector
Throttle
description
Valve
descr.
Function
V 8 Deflector
V6
V5 V4 V3 V2 V1
V7
…Hand operation
…
utomatic o
eration
V8
