INSTALLATION MANUAL - cod. 00 477 0811 - 12/2011 - Palazzetti - PN - Italy 47/144
USE AND & MAINTENANCE
ENGLISH
Fig. 9.1
9 STOVE OPERATION
9.1 STARTING THE STOVE
To start the stove hold the * button for several
seconds.
The display shows the message AWAITING
FLAME”. This stage of operation is automatic and
managed completely by the stove itself. During this
  
reach steady operating conditions.
Subsequently, the display will show the message
“FLAME ON”.
The stove will then automatically switch to the

for correct operation (using the same operating
parameters as when the stove was last started).
Automatic stove ignition: the stove comes with an
automatic device that starts the pellet stove without

       
automatic ignition system is not working correctly.

odours or smoke may be generated, caused by
evaporation or drying of certain materials used.
This phenomenon will gradually disappear.
The room should be well ventilated when starting

9.2 MODIFYING THE PARAMETERS
The stove operating parameters, described in
paragraph 7.2       
three different ways based on the type of interface
selected (scrolling, compressed or easy).
SCROLLING MENU

shown cyclically on the display. When needing to
modify a value, wait for the desired parameter to be
displayed (Power, Fan, Set Room T.) and use the
button to increase the value or the button to
decrease it.
COMPRESSED MENU
When the stove is in the “FIRE ON” stage (shown
on the first row of the display), to modify the
parameters simply press the
button to access
the menu for modifying the parameters, Fig. 9.1.
The display will show the parameters (P, F, T) and
four symbols indicating the functions of the menu
buttons (OK, X, +, -).
To move from one parameter to the next press

modify the value press
(“+”) or (“-”).
Once all the parameters have been set, press
!!
(“X”) to exit the menu.
To modify the parameters on the compressed menu

“OPERATING SETTINGS MENU” as illustrated in
paragraph 11.1.
The values set will be retained until next

off or unplugged from the power supply.
EASY MENU

room temperature using the up and down buttons.
Fan speed and power can not be changed. They
are automatically setted on “A”.
9.3 SWITCHING OFF
To switch the stove off hold the
!!
button for a few
seconds. The display will show the message “FINAL
CLEANING” and the stove will activate, for a few
minutes, an automatic procedure to shut down in
complete safety.
To start the stove again it’s recommended to wait
for the stove to cool down completely.
If attempting to start the stove again the display may
show the message “WAIT TO END CLEANING”,
asking the user to wait until the stove has shut down
completely.
The stove should only be switched off following the
procedure described above. Never switch the stove
off by unplugging it from the power supply.
9.3.1 !"#$%&'()*&#+$&,-)*/*0
The purpose of this warning is to ensure that the
burn pot is clean before ignition and consequently
guarantee the best possible stove operation.
Never pour the contents of the burn pot into the
pellet hopper.
After having cleaned the burn pot reset the warning
by pressing and holding the
!!
button.
