INSTALLATION MANUAL - cod. 00 477 0811 - 12/2011 - Palazzetti - PN - Italy 53/144
USE AND & MAINTENANCE
ENGLISH
Fig.12.1
12 ALRM MANAGEMENT
If a malfunction occurs, the stove responds as follows:
1) an audible alarm (beep) is emitted and the display shows the possible cause;
2) pellet feed stops;
Below is a list of the various alarm messages that may be shown on the display.
As well as the alarm message, the time and date the fault occurred are also displayed.
ALARM DESCRIPTION POSSIBLE CAUSE RESET
FLUE GAS
TEMP.
This alarm is activated if the flue gas
temperature is too low for correct stove
operation.
No pellets in the hopper.
Poor quality pellets (e.g. damp).
Standard procedure
“Reset alarms”
IGNITION
FAILED
This alarm is activated at the end of the
is too low for correct stove operation..
No pellets in the hopper
Poor quality pellets (e.g. damp)
Burn pot not positioned correctly or dirty.
Worn door or ash bin or burn pot gaskets.
Standard procedure
“Reset alarms”
HIGH TEMP.
Th i s al a rm i s act i vat e d wh e n th e
temperature inside the stove exceeds the
set safety values.
Power failure when the stove is operating.
Special maintenance required.
Faulty component.
Advanced procedure
“Reset high
temperature alarm”
EXHAUST
ERROR
This alarm is activated when the conditions
combustion air intake.
Flue blocked
Special maintenance required
Worn gaskets
Door or ash bin open
Standard procedure
“Reset alarms”
PELLET TEMP.
Th i s al a rm i s act i vat e d wh e n th e
temperature in the pellet hopper exceeds
the set safety values.
Power failure when the stove is operating.
Special maintenance required.
Faulty component.
Standard procedure
“Reset alarms”
FLUE FAN
This alarm is activated when a fault occurs
Flue gas exhaust fan fault.
Standard procedure
“Reset alarms”
PELLET / FLUE
PROBE
This alarm is activated when a fault occurs
in the operation of the temperature sensors:
Fault on one or both probes.
Standard procedure
“Reset alarms”
BLACK OUT
This alarm is activated in the event of an
extended power failure.
Extended power failure.
Standard procedure
“Reset alarms”
In order to start the stove again, operation must be reset as follows.
Standard procedure “Reset alarms”
2) Press the
OFF
button on the stove’s control panel for 5 seconds.
3) The display will show the message “Warning empty burn pot”.
4) Empty any residues from the burn pot; the stove will be ready to start again.
Advanced procedure!"#$%$&!'()'!&$*+$,-&/,$!-0-,*3!4+$,56,*$7!89!&'$!:$,;(<$!=$>&,$?
2) Unplug the stove from the power socket.
3) Unscrew the protection cap from thermostat with manual reset, located at the rear of the
stove.
4) Press the button on the thermostat to reset the stove, Fig.12.1.
5) Perform the standard procedure, “Reset alarms”, as described above.
If the alarm occurs twice consecutively, immediately contact a Palazzetti service centre.
If the external thermostat is being used and an alarm is activated, the stove can only be
started again from the control panel.
